Descriptions

Feature:

The excellent appearance accord with ergonomic design.

Integrated body design makes products maintain long-term stability.

Infinity achromatic correction optical system and common optical system can meet the different customers, requirements.

Specifications

Specification:

Objective: Grouped from any two objectives of 1X, 2X, 3X, and 4X.

Working Distance: 1X–55mm

2X–81mm

3X–61mm

4X–57mm

Wide field plan-Scope Eyepiece: WF10X (optional: WF15X, WF20X)

Total magnification: 10X–20X, or 10X–30X, or 10X–40X, or 20X–40X

Articulated free binocular head, interpupillary distance: 55–75mm, 45° Inclined

Illumination: top/bottom light

Lamp options: halogen lamp 6V/20W

incandescent lamp

LED lamp

LED lamp with rechargeable device

Stage plate: ф95mm Frosted Glass

Net weight (per set): 2.4kg

Package: 4 Sets/Carton (61 × 35 × 36cm)

Gross weight (per carton): 11kg
