Descriptions
Feature:
Smart Counting Mode
Smart WBC mode, smart PLT mode and smart WBC/PLT mode, specially designed for low-value samples.
Highly Integrated
24 parameters and 3 histograms with a built-in 10.4-inch touchscreen.
All-in-One Solution
Built-in printer and built-in card reader.
Convenient Operation
Strong data management: Information flagging for better diagnostic reference, large storage capacity, easy data transmission and quick QC file import.
Real-time monitoring: Tracks reagent status, temperature, pressure, voltage and current in real time.
Smart maintenance: 1-touch troubleshooting, hardware self-check and automatic alarms for abnormalities.
Specifications
Display
10.4-inch color touch screen
Throughput
60 samples per hour
Parameter
24 parameters: WBC, Neu#, Lym#, Gran#, Neu%, Lym%, Gran%, RBC, HGB, HCT, MCV, MCH, MCHC, RDW-SD, RDW-CV, PLT, MPV, PDW-SD, PDW-CV, PCT, P-LCR, P-LCC, NLR, PLR
3 histograms
Suitable for multiple animal
19 species: cat, dog, rabbit, sheep, goat, cattle, horse, rat, mouse, llama,deer, musk deer, monkey, tiger, dolphin, pig, camel, ferret, panda
Sample volume
10uL
Reagent
2 reagent (1 lyse+1 diluent)
1 probe detergent for maintenance
Calibration
manual and auto calibration available
Control
3 level QC
LJ graph, XB graph
Precision
WBC≤3.0%（6.0-15.0)×109/L
RBC≤3.0%（3.5-10.0)×1012/L
HGB≤2.0%（110.0-180.0)g/L
MCV≤1.0%（60.0-95.0)FL
PLT≤4.0%（150.0-500.0)×109/L
Linearity range
WBC: (1.00-200.0)×109/L
RBC: (0.30-17.00)×1012/L
HGB: (20.0-250.0)g/L
PLT: (20-5000)×109/L
Interface
4 USB ports, 1 Lan port, support WIFI adapter;
HL7 protocol, support Bi-directional LIS.
Printer
built-in thermal printer, optional external printer, built-in card reader
Storage
600,000 sample results with histograms
Power supply
AC 100-240V, 50/60±1Hz
Dimension
315*416*411mm(L*W*H)
Weight
26Kg
